Mateus Lana Posted June 19, 2023 Share Posted June 19, 2023 On 10/12/2021 at 22:44, Yorladis De Jesus Hernandez said: Olá amigo, você poderia fazer um para telas de 600x1024 ou me diga como fazer, sou novo nisso, não tenho ideia de como alterar as escalas e a imagem da cpu para colocar o nome intel tem o download? Quote Link to comment Share on other sites More sharing options...
Radames Posted June 19, 2023 Share Posted June 19, 2023 Olá amigo, leia novamente o post anterior ao meu. É muito trabalho para passar de 800x480 para 600x1024. Mas alterar entradas individuais é fácil: basta clicar na entrada com o segundo botão do rato e aparece um menu. Seleccione -Alterar-e pode escrever o que quiser AMD, Intel. Também é possível alterar a atribuição dos valores. Quote Link to comment Share on other sites More sharing options...
Arbit Posted June 19, 2023 Share Posted June 19, 2023 On 6/17/2023 at 4:51 PM, ROOFTURK said: How do you add things that aren't in the sensor panel by default? I want to add temperatures for my nvme drivers Right click on the panel. Choose sensor panel manager. Select new. Pick what item you want to display. Customize it. Put it in the correct position. Done. Quote Link to comment Share on other sites More sharing options...
Viper08 Posted June 20, 2023 Share Posted June 20, 2023 On 3/31/2022 at 6:06 AM, moonsalini said: Change my 800X480 screen to 1280x400 one. Took me some days to make new sensor one. P/s: I hope that this thread will keep up the spirit when it was first created, to share with people all beautiful panels to use for personal need but not for those copycat trying to steal others' works and sell for money. Thank you all and hope for the best! Would it be possible to get a copy of this? I’m installing a Y60 lcd display, sideways 3 Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 20, 2023 Share Posted June 20, 2023 On 6/2/2023 at 1:44 PM, Pfeffernuss said: Wow this is perfect! Has the panel been shared already or do you rather not do that? :-) Where can i find this one. like it much Quote Link to comment Share on other sites More sharing options...
Blacky67 Posted June 20, 2023 Share Posted June 20, 2023 (edited) A Versions of blue/red Simple Darkness_redV1.sensorpanel Simple Darkness_redV3.sensorpanel Simple Darkness_redV2.sensorpanel Edited June 20, 2023 by Blacky67 V2 added Quote Link to comment Share on other sites More sharing options...
Pixelhouse Posted June 20, 2023 Share Posted June 20, 2023 My first attempt at a sensorpanel. Resolution is 1280x480. This is a 6.8" LCD Screen named BeadaPanel 6P. It's still not finished, i would like to add a little background "noise" with some small elements here and there to fill in the areas in between the logo's and panels. The only thing i dislike is the fact that we cannot use animated gifs, i have the knowledge to make gifs, and would have liked to have each fan spinning slowly. Stat's it shows currently: CPU Usage % CPU Clock Speed CPU Temperature (graph) CPU Fan % (graph) (percentage is off on the AIDA64 software, works onscreen) ------------- GPU Usage % GPU Clock Speed GPU Temperature (graph) GPU Fan % (graph) ------------- Ram Usage % VRAM Usage VRAM Usage % (graph) GPU Fan % (graph) ------------- Date + Time ------------- FPS Counter ------------- 5 CaseFans + Usage % per fan (percentage is indicated by the green line, AIDA64 software does not show it, works onscreen) ------------- Hard Drive Usage for 2 Drives (if only using 1 drive, can use the 2nd line for drive activity) ------------- Total Download Size Total Upload Size Download Speed (graph) Upload Speed (graph) That's all, still work in progress, any feedback is appreciated. 6 Quote Link to comment Share on other sites More sharing options...
phoenix Posted June 20, 2023 Share Posted June 20, 2023 On 5/17/2023 at 7:19 AM, 서동훈 said: sensor panel white ver. 1920x1080 Do you have the PSD / original file for this template to edit the text on the actual image? 1 Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 20, 2023 Share Posted June 20, 2023 I would like to Say thank you very much for those who share their sensor profiles I could not have got started without your contributions. What I am curious about is some of them all being 1920x480 I import, and they are Perfect fit and I just have to change a few sensors to match my hardware. Import fonts etc. Some I will import, and the sensor window Grows Gauges will jump all over and i have to put everything where it should be. So why do some import perfectly to my 8.8 Panel and others do not even though they are formatted for same panel. Quote Link to comment Share on other sites More sharing options...
rnz055 Posted June 20, 2023 Share Posted June 20, 2023 I'm happy to share my first design for 480x320 AMD.sclcd Quote Link to comment Share on other sites More sharing options...
貢一君 Posted June 21, 2023 Share Posted June 21, 2023 15 hours ago, Pixelhouse said: センサーパネルでの私の最初の試み。 解像度は1280x480です。 これは、ビーダパネル6Pという名前の8.6インチLCDスクリーンです。 それはまだ終わっていません、私はロゴとパネルの間の領域を埋めるためにあちこちにいくつかの小さな要素で少し背景の「ノイズ」を追加したいと思います。 私が嫌いなのは、アニメーションGIFを使用できないという事実だけで、GIFを作成する知識があり、各ファンをゆっくりと回転させたかったのです。 統計は現在表示されています: CPU 使用率 % CPUクロック速度 CPU 温度 (グラフ) CPUファン%(グラフ)(AIDA64ソフトウェアではパーセンテージがオフで、画面上で動作します) ------------- GPU 使用率 % GPU クロック速度 GPU 温度 (グラフ) GPU ファン % (グラフ) ------------- ラム使用率 % VRAM の使用 VRAM 使用率 % (グラフ) GPU ファン % (グラフ) ------------- 日付 + 時刻 ------------- FPSカウンター ------------- 5 CaseFan + ファンあたりの使用率 % (パーセンテージは緑色の線で示され、AIDA64 ソフトウェアはそれを表示せず、画面上で動作します) ------------- 2台のドライブのハードドライブ使用量(1台のドライブのみを使用している場合は、ドライブアクティビティに2行目を使用できます) ------------- 合計ダウンロードサイズ 合計アップロードサイズ ダウンロード速度(グラフ) アップロード速度(グラフ) それだけです、まだ進行中の作業、どんなフィードバックも大歓迎です。 良いデザイン 3 Quote Link to comment Share on other sites More sharing options...
Arbit Posted June 21, 2023 Share Posted June 21, 2023 10 hours ago, Dudleydogg said: I would like to Say thank you very much for those who share their sensor profiles I could not have got started without your contributions. What I am curious about is some of them all being 1920x480 I import, and they are Perfect fit and I just have to change a few sensors to match my hardware. Import fonts etc. Some I will import, and the sensor window Grows Gauges will jump all over and i have to put everything where it should be. So why do some import perfectly to my 8.8 Panel and others do not even though they are formatted for same panel. It depends on your screen resolution and if you have any screen "magnification". My home screen is set to 150 percent so I can read the text on a high resolution monitor. If I didn't set it up that way everything would be tiny. That messes with everything on AIDA. I use the same sensor panels at home and work. (515x1920) the problem is that I use 2 different monitors with different resolutions and 2 different magnifications. When I work with Aida and import a home screen from work... Yup, it's a good couple hours moving things around to get it right. When imported the Aids screen is the wrong size and many items are even off the screen. It's something I really don't understand why it can be fixed by the programmers. If an item is set for x&y coordinates, they should be the same for any monitor no matter the resolution. If the panel size is the same and xy coordinates are set, it should work, should stay consistent, but doesn't. If I print out the coordinates from work, it makes for a faster transition... But still a pain. If you download a panel from here and don't have the original xy coordinates, it's a tedious process to get it right. Quote Link to comment Share on other sites More sharing options...
Grayson Posted June 21, 2023 Share Posted June 21, 2023 On 9/3/2021 at 12:54 PM, Liao Joey said: preview video below. Almost finished. I will release it before this Saturday. But there will be no download link... Still the old way.. Please leave your E-MAIL address. Or private message to me E-MAIL. I will send it to you... 20210903_184350.mp4 2.79 MB · 2 downloads m.pen@gmx.de. I love it. 1 1 Quote Link to comment Share on other sites More sharing options...
WayBadMojo Posted June 21, 2023 Share Posted June 21, 2023 Seconding the post above for corrective measures. I've also had luck making sure that my SensorPanel resolution is set in Preferences to match what is in the header of the SensorPanel file itself.. You can open a SensorPanel file in a text editor and the top lines will let you know what size it will try to display. Here's an example of the first 2 lines from one of mine: <SPVER>100</SPVER><SWVER>6.33.5766 Beta</SWVER> <SPWIDTH>1920</SPWIDTH><SPHEIGHT>480</SPHEIGHT><SPBGCOLOR>0</SPBGCOLOR> In this case it's a horizontal 1920x480 panel. -Mojo 1 Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 21, 2023 Share Posted June 21, 2023 you gave me some pointers directly and even when I do this the window still expands and items jump off to the extra space I can't force the window to Stop resizing. thank you all so much for the help with out this form i would have a Text only sensor panel LOL Quote Link to comment Share on other sites More sharing options...
Arbit Posted June 21, 2023 Share Posted June 21, 2023 2 hours ago, Dudleydogg said: you gave me some pointers directly and even when I do this the window still expands and items jump off to the extra space I can't force the window to Stop resizing. thank you all so much for the help with out this form i would have a Text only sensor panel LOL After looking at my own screens that I made for 515x1920 when I uploaded them and re-downloaded them to my work screen and install them The sensor panel was the wrong size. I had to go into the preferences under sensor panel and resize them for the correct size. I have no understanding why this happens. But this should probably help you as well. Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 22, 2023 Share Posted June 22, 2023 someone said the same thing, I have a 8.8 Waveform monitor its 1920x480 and its set to 100% no mag on text etc. I can open my fav panel a dark min one and its Spot on, all the others it spreads out, I even lock position. so even though I am not magnifying anything on that 8.8 monitor maybe its affecting Aida64? my other main monitors are set at 150%. Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 22, 2023 Share Posted June 22, 2023 When I resize them even if on the 1920x480 screen all the sensors move, I have found 3 panels that just open perfectly so far out of like 100's LOL few tweeks and they are ready. I have the app locked "Lock Panel Size" yet it still resizes it. Quote Link to comment Share on other sites More sharing options...
Dudleydogg Posted June 22, 2023 Share Posted June 22, 2023 FYI it was a DPI Scaling feature once i disabled that and locked to System, i can use all the other sensor panels now. They scale to my 8.8 screen perfectly. Quote Link to comment Share on other sites More sharing options...
AezielOfficiel Posted June 22, 2023 Share Posted June 22, 2023 515x1920 ( 515 x 1920 ) DeadpoolRB.sensorpanel 4 Quote Link to comment Share on other sites More sharing options...
貢一君 Posted June 22, 2023 Share Posted June 22, 2023 9年2月2021日午後11:00に、リャオジョーイは次のように述べています。 ご意見ありがとうございます...これが現在の進捗状況です...約60%... 共有願います。kouichi144@gmail.com Quote Link to comment Share on other sites More sharing options...
cepy7 Posted June 22, 2023 Share Posted June 22, 2023 Black Modif ..480 x 800 Quote Link to comment Share on other sites More sharing options...
cepy7 Posted June 22, 2023 Share Posted June 22, 2023 Just now, cepy7 said: Black Modif ..480 x 800 Quote Link to comment Share on other sites More sharing options...
Arbit Posted June 22, 2023 Share Posted June 22, 2023 16 hours ago, Dudleydogg said: FYI it was a DPI Scaling feature once i disabled that and locked to System, i can use all the other sensor panels now. They scale to my 8.8 screen perfectly. That's in the windows"magnification" area, not in Aida, correct? Quote Link to comment Share on other sites More sharing options...
WayBadMojo Posted June 23, 2023 Share Posted June 23, 2023 5 hours ago, Arbit said: That's in the windows"magnification" area, not in Aida, correct? It's a Windows compatibility setting that you apply on the EXE itself... Locate AIDA64.EXE (C:\Program Files (x86)\FinalWire\AIDA64 Extreme) 1) Right Click 2) Properties 3) Compatibility Tab 4) 'Change High DPI settings' 5) Check 'Override High DPI Scaling' 6) Scaling performed by: 'System' (from the drop down) 7) Ok/Apply 8) Restart Windows Once you've done this, make sure that your SensorPanel properties are set to match the new panel before importing and you have a better chance of being successful. -Mojo 2 Quote Link to comment Share on other sites More sharing options...
