Share your Sensorpanels


Mice007

Recommended Posts

2 hours ago, Viper08 said:

good afternoon,



i installed the y60 sensor panel in my pc and would love to get a cool looking one to display my tems and such on it. i have a 1920 x 515 panel  i have a CPU 13900K and GPU Nvidia 4090 suprim liquid is there anyone that could point me where i would down load the skin and font needed?  I have to buy AIDA64 i guess to make it work right?

My ASUS ROG came with a licensed version from their AI-Suite of apps. For font install just double click on it in windows and click install when the font page comes up. I'm not sure what size your panel is so once you find the resolution just search for that size.

Link to comment
Share on other sites

On 7/10/2023 at 10:33 PM, Not Tony Hawk said:

I've downloaded several different .sensorpanel templates, all 600x1024, and every panel I import looks like the one bellow. Anyone have any idea what im doing wrong?

Screenshot 2023-07-10 222906.png



This has to do with the display Scale and how AIDA64 handles it.

See a way to fix the Scale problem here:



Link to comment
Share on other sites

On 7/4/2023 at 9:02 AM, stemline1 said:

Tell me, what's the problem? the touchpad is always like this... at any screen resolution... the screen scale is always 100%

Без имени.jpg

The problem could be one of two issues:

1. You didn't import the fonts; or

2. Your display Scale is greater than 100%.  Check out this post where this particular issue was resolved.  if this is your issue, then it's because AIDA64 adopts the Scale of the main display where it starts up, so if the display Scale is greater than 100%, then AIDA64 adopts that Scale when it runs, which has the effect of enlarging all your fonts making everything in your Sensor Panel display improperly; but you can prevent AIDA64 from adopting the Scale of whatever monitor it runs on.  By forcing AIDA64 to ignore the display Scale, it will always run at a Scale of 100% and the fonts will display properly.





Link to comment
Share on other sites

On 6/22/2023 at 11:57 PM, WayBadMojo said:

It's a Windows compatibility setting that you apply on the EXE itself...
Locate AIDA64.EXE (C:\Program Files (x86)\FinalWire\AIDA64 Extreme)

1) Right Click
2) Properties
3) Compatibility Tab
4) 'Change High DPI settings'
5) Check 'Override High DPI Scaling'
6) Scaling performed by: 'System' (from the drop down)
7) Ok/Apply
8) Restart Windows

Once you've done this, make sure that your SensorPanel properties are set to match the new panel before importing and you have a better chance of being successful.



-Mojo

Great job, Mojo!

I spent a lot of time trying to figure this out.  I documented two resolutions, one temporary and one permanent.  You mentioned the permanent solution, but there is a catch.  I found a few additional steps:  set the display scale to 100%, run AIDA64 to be sure it adopts that scale.  I restarted Windows, too, to be sure the Scale was "clean" for AIDA64.  Then I did what you did and started AIDA64.  From then on, AIDA64 ignored the display Scale and remained at a Scale of 100% regardless of the Scale of the display.



AIDA64 should adopt the resolution and scale of the destination monitor or have an option to set the monitor affinity for the Sensor Panel thus forcing the Sensor Panel to adopt the Scale of that display.  They can also stop "updating" the size of the Sensor Panel even though the display scale is more than 100%.  I'm sure there's some work that can be done there, but AIDA64 said this was an unexpected problem and I don't think they're all that interested in fixing this.

Link to comment
Share on other sites

On 6/21/2023 at 5:05 AM, Arbit said:

It depends on your screen resolution and if you have any screen "magnification". My home screen is set to 150 percent so I can read the text on a high resolution monitor. If I didn't set it up that way everything would be tiny. That messes with everything on AIDA. I use the same sensor panels at home and work. (515x1920) the problem is that I use 2 different monitors with different resolutions and 2 different magnifications. When I work with Aida and import a home screen from work... Yup, it's a good couple hours moving things around to get it right. When imported the Aids screen is the wrong size and many items are even off the screen. It's something I really don't understand why it can be fixed by the programmers. If an item is set for x&y coordinates, they should be the same for any monitor no matter the resolution. If the panel size is the same and xy coordinates are set, it should work, should stay consistent, but doesn't. If I print out the coordinates from work, it makes for a faster transition... But still a pain. If you download a panel from here and don't have the original xy coordinates, it's a tedious process to get it right.

The resolution to the Scale problem with multiple monitors is found here:



Link to comment
Share on other sites

On 2/24/2021 at 5:31 PM, pcanuck said:

When I open it in AIDA64 it comes up like this:

https://www.dropbox.com/s/j2cb5tkpj2go0e1/CaptureGodzillaPanel.PNG

Other 800x480 templates result in the same effect.  I know I'm doing something wrong - just not sure what - first time trying AIDA64.  When i 'resize' to 800x480, it just shrinks the panel size not the other elements.

Thanks in advance for any tips!



I know this post is rather old, but the issue deals with the Scale of the main display.  On my system, I have to use a Scale of 150% and on the 2nd display, the Scale is 100%.  Nevertheless, when AIDA64 starts, it starts in the main display and uses the Scale of 150% regardless of the setting of the Sensor Panel.  The fix is to force AIDA64 to ignore the DPI and Scale of the main monitor.  The solution is found here.





Link to comment
Share on other sites

On 8/18/2021 at 9:44 PM, Liao Joey said:

ZERO V2 1024X600

The theme function is the same as ZERO V2 1920X480. which with animation effects. Audio visualizer effects.Because my work is too busy, I haven't finished it until now...Please read the installation instructions (read_me_first.txt) before you use.

enjoy it !

preview


download link (Delete after 7 days)

hey is it possible u can send a download link of this if u have one in 480x1920 my email is owenrice35@gmail.com

Link to comment
Share on other sites

On 6/25/2023 at 11:41 PM, joransrb said:

STARFIELD v2


DOWNLOAD HERE

I made a 480x1920 of your template, sharpened the text and borders/icons, and moved some of the text from the background to the Sensor Panel labels so it can be changed more easily, also resized the custom gauge to fit this new format. Also made some new color themes (you'll find everything in the folder called backgrounds)

Took about 8 hours so hope you guys enjoy it. All credits to the original creator.

Desktop Screenshots:

image.thumb.png.a2b80b00336b781b106d8a5bd0e93795.png  image.thumb.png.884630b3c0b6f4fe5036987763600dbf.png  image.thumb.png.ba93683a6f9b2bde3d0e15be630ab529.png

  image.thumb.png.d164d2e5cb4acc48f2874e24ffcd0f36.png  image.thumb.png.6c3a1813ce43df52c77076a5f183191e.png  image.thumb.png.035a75ca1c40356447e24d6957a9a465.png



In case pictures:



1418361538_StarfieldCustomSensorPanel.zip

  • Like 11
  • Thanks 5
Link to comment
Share on other sites

1 hour ago, FIIZiK said:

I made a 480x1920 of your template, sharpened the text and borders/icons, and moved some of the text from the background to the Sensor Panel labels so it can be changed more easily, also resized the custom gauge to fit this new format. Also made some new color themes (you'll find everything in the folder called backgrounds)

Took about 8 hours so hope you guys enjoy it. All credits to the original creator.

Desktop Screenshots:

image.thumb.png.a2b80b00336b781b106d8a5bd0e93795.png  image.thumb.png.884630b3c0b6f4fe5036987763600dbf.png  image.thumb.png.ba93683a6f9b2bde3d0e15be630ab529.png

  image.thumb.png.d164d2e5cb4acc48f2874e24ffcd0f36.png  image.thumb.png.6c3a1813ce43df52c77076a5f183191e.png  image.thumb.png.035a75ca1c40356447e24d6957a9a465.png



In case pictures:



1418361538_StarfieldCustomSensorPanel.zip 5.27 MB · 2 downloads

What panel is that? Got any more build pics?

Link to comment
Share on other sites

2 hours ago, FIIZiK said:

I made a 480x1920 of your template, sharpened the text and borders/icons, and moved some of the text from the background to the Sensor Panel labels so it can be changed more easily, also resized the custom gauge to fit this new format. Also made some new color themes (you'll find everything in the folder called backgrounds)

Took about 8 hours so hope you guys enjoy it. All credits to the original creator.

Desktop Screenshots:

image.thumb.png.a2b80b00336b781b106d8a5bd0e93795.png  image.thumb.png.884630b3c0b6f4fe5036987763600dbf.png  image.thumb.png.ba93683a6f9b2bde3d0e15be630ab529.png

  image.thumb.png.d164d2e5cb4acc48f2874e24ffcd0f36.png  image.thumb.png.6c3a1813ce43df52c77076a5f183191e.png  image.thumb.png.035a75ca1c40356447e24d6957a9a465.png



In case pictures:



1418361538_StarfieldCustomSensorPanel.zip 5.27 MB · 2 downloads

Hello ,
Your panels are very nice.
Thank you very much for sharing.

Link to comment
Share on other sites

On 11/3/2021 at 11:13 PM, Shrike said:

Hello guys.
So I Wanted to get a Corsair Nexus originally for on keyboard hardware monitor but the 99$ price felt way too much for that useless piece of hardware. Decided to make my own Nexus mode (Pretty sure I saw 2 more similar style modes later on reddit also.) but here's my take on it. :D

Got a 7.9 inch 1280X400 Waveshare screen since I wanted to keep the design language similar to Corsair Nexus. Unfortunately this model came with a bit of challenges. No casing was available for this and more than that veerryyy less amount of 1280x400 size sensor panels here, almost close to none.
So first, custom DIY'd made the case from stuff laying in my storage. Mainly my LGv40 case and Intel CPU box. :ph34r:


For sensor panel I used the base panel of "Exhumed" And "Rodney" and a few stuff from Cyberpunk pack, edited and created a 966X400 size panel. Update the stuff I needed and fit in it with design changes in photoshop.


And for the side extra space left on the 1280x400 display. I Pre-searched for cyberpunk wallpaper on Wallpaper Engine which had some cool animations and Audio reactive panel.


So according to the middle empty area I choose the panel resolution later. once this was done. Sensor panel fitted perfectly between the Wallpaper and the whole 1280X400 size is being used.


Took me a while to figure out stuff. But worked out okay in the end :D And cost total of 96$ including long cables and screen.
Now I know there are a lot of Chinese prebuild screens of this ratio and some of lamptron too. But well China isn't shipping to India anymore and anything from US/UK store will cost a lot of extra money for shipping. This wholly was done keeping the goal budget of 99$ in mind.


20211031_2003591.thumb.jpg.50427862573b3c4ce89b44a957b27a83.jpgPeace <3


Hey, amazing work, can you share it in 1280x400 ?? thanks

Link to comment
Share on other sites

On 3/15/2022 at 4:28 PM, Babaz said:

Hello I modified a Sensor Panel of a user that I found here on this forum.

Thank you all for sharing.

Bonjour j'ai modifié un Sensor Panel d'un utilisateur que j ai trouver ici sur ce forum.

Merci a tous pour le partage.



https://uploadnow.io/f/zJrJkn7



SensorPanel_1400_modifié_par_Babaz.sensorpanel




Sensor panel.png

Could you possibly re-upload the file? It looks like both links are broken. Sick panel!!

Link to comment
Share on other sites

On 7/22/2023 at 3:47 PM, FIIZiK said:

I made a 480x1920 of your template, sharpened the text and borders/icons, and moved some of the text from the background to the Sensor Panel labels so it can be changed more easily, also resized the custom gauge to fit this new format. Also made some new color themes (you'll find everything in the folder called backgrounds)

Took about 8 hours so hope you guys enjoy it. All credits to the original creator.

Desktop Screenshots:

image.thumb.png.a2b80b00336b781b106d8a5bd0e93795.png  image.thumb.png.884630b3c0b6f4fe5036987763600dbf.png  image.thumb.png.ba93683a6f9b2bde3d0e15be630ab529.png

  image.thumb.png.d164d2e5cb4acc48f2874e24ffcd0f36.png  image.thumb.png.6c3a1813ce43df52c77076a5f183191e.png  image.thumb.png.035a75ca1c40356447e24d6957a9a465.png



In case pictures:



1418361538_StarfieldCustomSensorPanel.zip 5.27 MB · 42 downloads

that looks really cool, great work. I might have to get a 480x1920 display for this

  • Thanks 3
  • Haha 1
Link to comment
Share on other sites
