18 hours ago, Nashö said:

Want to share my latest project. Currently 90% in progress..

The elements were from you guys who sharing your Sensor Panel here thus, thank you so much.

This template is made to accommodate my upcoming long screen (ordered locally) and gotta say that I am proud with this one. The resolution is 1920x480. The fan gauge were custom made including the ram graph (impractical i know lol).

I ll share the template soon enough when its completed.


Really love the design. Can't wait for you to complete this!

Link to comment
Share on other sites

On 1/21/2021 at 5:05 PM, Nashö said:

Credit to @miishb79for the template and (sorry i forgot whose sensors) for the "RYZ5N" words.

I really like the "stacking" graph on this template and how it looks futuristic.

Thus I have made a little bit of change on resolution to fit on my panel which 1024x600 and some edits on colours and fonts (name: Robot Reavers) to match my theme.



Sci-Fi (Ryz5n Version).sensorpanel 1.9 MB · 93 downloads

hi bro newbie here.. yours absolutely one of the best looking sensor panel here.. mind to share me the panel in 800x480

Link to comment
Share on other sites

Vor 1 Stunde sagte die Erfolgslosigkeit:

Wenn Sie eine bestimmte oder andere wichtige Rechte haben, gehen Sie einfach zu Ihren Einstellungen und ändern Sie die Anzahl in der Auflösung.


Hab ich auch probiert ...

Leider erfolglos alles was im schwarzen Bereich ist wird ausgeblendet ..

Beide Displays sind an der graka abgeschlossen, mein Haupt Bildschirm läuft auf 1080

Der 7 Zoll mit 1024 mal 600

Und ist alls erweiterung vom Haupbildschirm eingestellt.

Link to comment
Share on other sites

8 minutes ago, Arnold Fleischer said:

Hab ich auch probiert ...

Leider erfolglos alles was im schwarzen Bereich ist wird ausgeblendet ..

Beide Displays sind an der graka abgeschlossen, mein Haupt Bildschirm läuft auf 1080

Der 7 Zoll mit 1024 mal 600

Und ist alls erweiterung vom Haupbildschirm eingestellt.

It sounds like you have to edit everything in 1080. Move all the items in the black area (excess area) into the smaller 1024x600 area. To move items, right click over the item and choose "move". Move it to 1024x600 area. Then change the preference to 1024x600 and those items should now be visible.

  • Like 1
Link to comment
Share on other sites

21 minutes ago, successlessness said:

It sounds like you have to edit everything in 1080. Move all the items in the black area (excess area) into the smaller 1024x600 area. To move items, right click over the item and choose "move". Move it to 1024x600 area. Then change the preference to 1024x600 and those items should now be visible.

gibt es keine andere möglichkeit .auser das man die einzelnen elemente zu verschieben ?

oder bibt es die möglochkeit den 7 zoll auch auf 1080 zu stellenund das entsprechende pannel einzufügen?



Link to comment
Share on other sites

14 minutes ago, Arnold Fleischer said:

gibt es keine andere möglichkeit .auser das man die einzelnen elemente zu verschieben ?

oder bibt es die möglochkeit den 7 zoll auch auf 1080 zu stellenund das entsprechende pannel einzufügen?



I don't think the software will automatically resize or rescale for you. If there is, I don't know it or have I seen that option in setting.

When I changed resolution, I had to manually move things around one at a time.

Link to comment
Share on other sites

For those interested, here is my final Fallout sensor build (see attached zip file). I ended removing a lot of stats I didn't care for, to keep it clean... but obviously you should modify it to your needs.

It is for 1024x600 resolution. You might want to install the monofont (I've included it in the zip file), but it is not necessary.  I've also included a screen shot of the panel - but as of this writing I realized the computer has been up for two days and I should probably reboot or change AID64 to seven days.

I've also made a video tour of the display and interior computer here:

Fallout-Final-Sensorpanel.zipup


  • Like 9
  • Thanks 1
Link to comment
Share on other sites

Hi, I'm new here on the AIDA 64 forum and I also built myself a small custom sensor panel based on NZXT CAM.

I set the gauges images to 180x180px because my LCD display has a resolution of 1024x600 and so I can see it better.

My problem is that the temperature, always from 43 degrees, sprints to the top left and the display bar disappears.

So far I could not find out why this is so.
Does anyone have an idea?


Edited by Bathord906
Foto
  • Like 1
Link to comment
Share on other sites

On 1/17/2021 at 8:42 PM, Thomas C. Riddell said:

So I just finished mine my 1st attempt at one of these Panels

I used a old Samsung s5 Phone and Program called Spacedesk on phone

Then Installed the Driver for spacedesk to the PC .

This gave me a 3rd Monitor

Used Velcro to Hold the phone into place. (make easy to make changes that way )

I then Plug the phone into USB Ports  set phone for 1920X1080

Also set that in Aida64 Software Preferences

Made all Graphics and set up my Panel took me 7 hours

still trying to learn how add Graphics FPS and Internet Traffic Info

so any help or videos I could watch would be help

Thanks for this Great Program







I was looking at IPS panels but I have an iPad mini that I'm no longer using. Will see if I can get it running for this as it will Integrate into the white theme I have going. I also have a few Android devices lying about that would work if I can't get the iPad working



Great job. And thanks for the idea...

Link to comment
Share on other sites

On 1/25/2021 at 3:07 AM, Nashö said:

Want to share my latest project. Currently 90% in progress..


Looking forward to your next work, @Nashö.  Very clean!

I also have an 8.8 inch panel on order.  It should be delivered in the next 2 weeks.  While waiting, I have already created a design based off of the popular Fantasy of Space theme and work from @teetaatee

Will also upload after I test and tweak on the actual display.





Aida Spy - B3.JPG

  • Like 8
Link to comment
Share on other sites

4 hours ago, Nghia Phan said:

A clean NZXT panel for 1024x600px resolution...

Font: Agency FB

There are also different backgrounds that u can choose. In that case u have to change the color for the text though....


Large Gauges.zip 50.93 kB · 1 download Small Gauges.zip 26.31 kB · 0 downloads NZXT-background.zip 136.85 kB · 1 download NZXT-panel.sensorpanel 194.49 kB · 2 downloads

Looks very good.



What size gauges did you choose?

Mine are 180x180 pixels and I have the problem that the number in the middle always slips into the left corner when 43 degrees are exceeded.

Then the bar also disappears.



I have no idea why this happens.




Link to comment
Share on other sites

10 hours ago, Nghia Phan said:

A clean NZXT panel for 1024x600px resolution...

Font: Agency FB

There are also different backgrounds that u can choose. In that case u have to change the color for the text though....


Large Gauges.zip 50.93 kB · 6 downloads Small Gauges.zip 26.31 kB · 4 downloads NZXT-background.zip 136.85 kB · 5 downloads NZXT-panel.sensorpanel 194.49 kB · 10 downloads

This is amazing, thank you. I try to make for 800x480 but cannot do. I am new so may need a litlle help

  • Like 1
Link to comment
Share on other sites

9 hours ago, Bathord906 said:

Looks very good.



What size gauges did you choose?

Mine are 180x180 pixels and I have the problem that the number in the middle always slips into the left corner when 43 degrees are exceeded.

Then the bar also disappears.



I have no idea why this happens.




You should double check if you have selected the correct file for all 16 gauges. I think you missed one of them and that's why it disappeared. In additional, mine are 144x144px for the large gauges.

Link to comment
Share on other sites

3 hours ago, Vimyscout said:

This is amazing, thank you. I try to make for 800x480 but cannot do. I am new so may need a litlle help

There is already an 800x480 version online. Mine is just an upgrade from this version. I can post the link here if you are interested. It is from a guy on youtube

https://drive.google.com/drive/u/0/folders/1JeiJRmouRjlOltMzdYSs8LcOkfIjt2vh

  • Like 6
