AIDA64 Discussion Forum
PierrotIV

fixed: Nuvoton NCT6791D sensor readings not showing (Asus Sabertooth Z87)

Recommended Posts

10 hours ago, PierrotIV said:

Hi,

In last beta 4944, the Nuvoton NCT6791D is not showing any sensor.

In the previous 4936 it was working.

Hope this helps ;)

Regards,

PierrotIV

We've updated the kernel drivers.  Make sure to restart Windows to apply the changes.

Share this post


Link to post
Share on other sites
15 hours ago, PierrotIV said:

Hi,

Restarting windows does not change the situation. The sensors are not reported any more.

Regards,

PierrotIV

Thank you for your reply.  Something must have been mixed up after the upgrade.  Please try to close AIDA64, download the latest beta ZIP package, extract the whole contents into the existing installation folder of AIDA64, and let it overwrite any existing files.  Restart Windows one more time, and check if it works.  If not, then please check if your motherboard is properly identified (on the Computer / Summary page of AIDA64 for example).

Share this post


Link to post
Share on other sites
On 2/8/2019 at 4:16 PM, Fiery said:

Thank you for your reply.  Something must have been mixed up after the upgrade.  Please try to close AIDA64, download the latest beta ZIP package, extract the whole contents into the existing installation folder of AIDA64, and let it overwrite any existing files.  Restart Windows one more time, and check if it works.  If not, then please check if your motherboard is properly identified (on the Computer / Summary page of AIDA64 for example).

Hi,

Thanks for your reply and help ;)

After uninstalling the previous aida64 and restarting the computer, I extracted the latest beta zip in a new folder (without keeping the ini from the previous install).

Symptoms are exactly the same as in my initial post and the motherboard is correctly identified in computer / summary page.

PierrotIV

Share this post


Link to post
Share on other sites
12 hours ago, PierrotIV said:

Hi,

Thanks for your reply and help ;)

After uninstalling the previous aida64 and restarting the computer, I extracted the latest beta zip in a new folder (without keeping the ini from the previous install).

Symptoms are exactly the same as in my initial post and the motherboard is correctly identified in computer / summary page.

PierrotIV

It's very odd :(  Please right-click on the bottom status bar of AIDA64 main window --> Sensor Debug --> ISA Sensor Dump. Copy-paste the full results into this topic, or attach the results as a TXT file to your post. You may need to enable status bar in AIDA64 / main menu / View first.


Thanks,
Fiery

Share this post


Link to post
Share on other sites
2 hours ago, Fiery said:

It's very odd :(  Please right-click on the bottom status bar of AIDA64 main window --> Sensor Debug --> ISA Sensor Dump. Copy-paste the full results into this topic, or attach the results as a TXT file to your post. You may need to enable status bar in AIDA64 / main menu / View first.


Thanks,
Fiery

Hi,

Here they are:

------[ Versions ]------

Program Version : AIDA64 Extreme v5.99.4944 Beta
BenchDLL Version: 4.3.793-x64
Windows Version : Microsoft Windows 10 Pro 10.0.17763.292 (64-bit)

------[ Motherboard Info ]------

Motherboard ID      : <DMI>
Motherboard Model   : Asus Sabertooth Z87
Motherboard Chipset : Intel Lynx Point Z87, Intel Haswell

DMI MB Manufacturer : ASUSTeK COMPUTER INC.
DMI MB Product      : SABERTOOTH Z87
DMI MB Version      : Rev 1.xx
DMI MB Serial       : 130612993601778
DMI SYS Manufacturer: ASUS
DMI SYS Product     : All Series
DMI SYS Version     : System Version
DMI SYS Serial      : System Serial Number
DMI BIOS Version    : 2302

ITE SuperIO Port           = 00h
ITE SuperIO HWMonitor Port = 0000h     (    0000h /     0000h)
ITE SuperIO HWMonitor MMIO = 00000000h (00000000h / 00000000h)
ITE SuperIO Device ID      = 0000h     (    0000h /     0000h)
ITE SuperIO Version        = 00h       (      00h /       00h)

Winbond SuperIO Port              = 00h
Winbond SuperIO HWMonitor Port/60 = 0000h (0000h / 0000h)
Winbond SuperIO HWMonitor Port/64 = 0000h (0000h / 0000h)
Winbond SuperIO Device ID         = 0000h (0000h / 0000h)

Fintek SuperIO Port           = 00h
Fintek SuperIO HWMonitor Port = 0000h (0000h / 0000h)
Fintek SuperIO Device ID      = 0000h (0000h / 0000h)

SMSC SuperIO Port           = 00h
SMSC SuperIO HWMonitor Port = 0000h (0000h / 0000h)
SMSC SuperIO Device ID      = 0000h (0000h / 0000h)

ASpeed SuperIO Port = 00h

------[ ACPI Temperatures & Fans ]------

_TZ_.THM0._TMP             :
_TZ_.THM1._TMP             :
_TZ_.THR0._TMP             :
_TZ_.THR1._TMP             :
_TZ_.TZ00._TMP             :
_TZ_.TZ01._TMP             :
_TZ_.RTMP                  :
_TZ_.RFAN                  :
_TZ_.RFAN(0)               :
_TZ_.RFAN(1)               :
_SB_.ATKD._HID             :
_SB_.ATKD.TMPR             :
_SB_.PCI0.LPC0.EC0_.CCTV   :
_SB_.PCI0.LPC0.EC0_.LRPM   :
_SB_.PCI0.LPC0.EC0_.HRPM   :
_SB_.PCI0.SBRG.EC0_.ECPU   :
_SB_.PCI0.SBRG.EC0_.TACH(0):
_SB_.PCI0.SBRG.EC0_.TACH(1):
_SB_.PCI0.SBRG.EC0_.TAH0   :
_SB_.PCI0.SBRG.EC0_.TAH1   :
_SB_.PCI0.SBRG.EC0_.ST00   :
_SB_.PCI0.SBRG.EC0_.SC01   :
_SB_.PCI0.SBRG.EC0_.SC02   :
_SB_.PCI0.SBRG.EC0_.SC03   :
_SB_.PCI0.SBRG.EC0_.SC04   :
_SB_.PCI0.SBRG.EC0_.SC05   :
_SB_.PCI0.SBRG.EC0_.SC06   :
_SB_.PCI0.SBRG.EC0_.TH0R   :
_SB_.PCI0.SBRG.EC0_.TH1R   :
_SB_.PCI0.SBRG.EC0_.F0TS   :
_SB_.PCI0.SBRG.EC0_.F1TS   :
_SB_.PCI0.PIB_.EC0_.TCRT   :
_SB_.PCI0.SBRG.EC0_.CTPM   :
_SB_.PCI0.SBRG.EC__.CPUT   :
_SB_.PCI0.SBRG.EC__.SYST   :
_SB_.PCI0.LPC_.EC0_.CTMP   :
_SB_.PCI0.LPCB.EC0_.CTMP   :
_SB_.PCI0.LPC_.EC0_.TMP1   :
_SB_.PCI0.LPC_.EC0_.TMP2   :
_SB_.PCI0.LPC_.EC0_.TMPI   :
_SB_.PCI0.LPC_.EC0_.TMPV   :
_SB_.PCI0.LPCB.EC0_.A1TP   :
_SB_.PCI0.LPCB.EC0_.A2TP   :
_SB_.PCI0.LPCB.EC0_.FAN0   :
_SB_.PCI0.LPCB.EC__.TS1R   :
_SB_.PCI0.LPCB.EC__.TS2R   :
_SB_.PCI0.LPCB.EC__.TS3R   :
_SB_.PCI0.LPCB.EC__.F1FL   :
_SB_.PCI0.LPCB.EC__.F1FH   :
_SB_.PCI0.LPCB.EC__.F2FL   :
_SB_.PCI0.LPCB.EC__.F2FH   :
_SB_.PCI0.LPC_.H8EC.RTMP   :
_SB_.PCI0.LPC_.H8EC.LTMP   :
_SB_.PCI0.LPC_.H8EC.MTMP   :
_SB_.PCI0.LPC_.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.CTMP   :
_SB_.PCI0.LPCB.H8EC.DTMP   :
_SB_.PCI0.LPCB.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.ITMP   :
_SB_.PCI0.LPCB.H8EC.MTMP   :
_SB_.PCI0.LPCB.H8EC.STMP   :
_SB_.PCI0.LPCB.H8EC.PFAN   :
_SB_.PCI0.LPCB.EC0_.OTPC   :
_SB_.PCI0.LPCB.EC0_.VGAT   :
_SB_.PCI0.LPCB.EC0_.CHPT   :
_SB_.PCI0.LPCB.EC0_.CPUT   :
_SB_.PCI0.LPCB.EC0_.SYST   :
_SB_.PCI0.LPCB.EC0_.DTS1   :
_SB_.PCI0.LPCB.EC0_.DTS2   :
_SB_.PCI0.LPCB.EC0_.DIMM   :
_SB_.PCI0.LPCB.EC0_.FANH   :
_SB_.PCI0.LPCB.EC0_.FANL   :
_SB_.PCI0.LPCB.EC0_.CUTP   :
_SB_.PCI0.LPCB.EC0_.PHTP   :
_SB_.PCI0.LPCB.EC0_.DIMT   :
_SB_.PCI0.LPCB.EC0_.INLE   :
_SB_.PCI0.LPCB.EC0_.PANT   :
_SB_.PCI0.LPCB.EC0_.F0RM   :
_SB_.PCI0.LPCB.EC0_.F0DT   :
_SB_.PCI0.LPCB.EC0_.F1RM   :
_SB_.PCI0.LPCB.EC0_.F1DT   :
_SB_.PCI0.SBRG.EC0_.CUTP   :
_SB_.PCI0.SBRG.EC0_.PHTP   :
_SB_.PCI0.SBRG.EC0_.DIMT   :
_SB_.PCI0.SBRG.EC0_.INLE   :
_SB_.PCI0.SBRG.EC0_.PANT   :
_SB_.PCI0.SBRG.EC0_.F0RM   :
_SB_.PCI0.SBRG.EC0_.F0DT   :
_SB_.PCI0.SBRG.EC0_.F1RM   :
_SB_.PCI0.SBRG.EC0_.F1DT   :
_SB_.SAMB.TMPC             :
_SB_.SAMB.TMPH             :
_SB_.STR0._TMP             :
_SB_.STR1._TMP             :
_SB_.STR2._TMP             :
_SB_.STR3._TMP             :
_SB_.STR4._TMP             :
_SB_.STR5._TMP             :
_SB_.STR6._TMP             :
_SB_.STR7._TMP             :
CPUT                       :
GPUT                       :
SYST                       :
FANT                       :
BATT                       :


Thank you.

Share this post


Link to post
Share on other sites
20 minutes ago, PierrotIV said:

Hi,

Here they are:

------[ Versions ]------

Program Version : AIDA64 Extreme v5.99.4944 Beta
BenchDLL Version: 4.3.793-x64
Windows Version : Microsoft Windows 10 Pro 10.0.17763.292 (64-bit)

------[ Motherboard Info ]------

Motherboard ID      : <DMI>
Motherboard Model   : Asus Sabertooth Z87
Motherboard Chipset : Intel Lynx Point Z87, Intel Haswell

DMI MB Manufacturer : ASUSTeK COMPUTER INC.
DMI MB Product      : SABERTOOTH Z87
DMI MB Version      : Rev 1.xx
DMI MB Serial       : 130612993601778
DMI SYS Manufacturer: ASUS
DMI SYS Product     : All Series
DMI SYS Version     : System Version
DMI SYS Serial      : System Serial Number
DMI BIOS Version    : 2302

ITE SuperIO Port           = 00h
ITE SuperIO HWMonitor Port = 0000h     (    0000h /     0000h)
ITE SuperIO HWMonitor MMIO = 00000000h (00000000h / 00000000h)
ITE SuperIO Device ID      = 0000h     (    0000h /     0000h)
ITE SuperIO Version        = 00h       (      00h /       00h)

Winbond SuperIO Port              = 00h
Winbond SuperIO HWMonitor Port/60 = 0000h (0000h / 0000h)
Winbond SuperIO HWMonitor Port/64 = 0000h (0000h / 0000h)
Winbond SuperIO Device ID         = 0000h (0000h / 0000h)

Fintek SuperIO Port           = 00h
Fintek SuperIO HWMonitor Port = 0000h (0000h / 0000h)
Fintek SuperIO Device ID      = 0000h (0000h / 0000h)

SMSC SuperIO Port           = 00h
SMSC SuperIO HWMonitor Port = 0000h (0000h / 0000h)
SMSC SuperIO Device ID      = 0000h (0000h / 0000h)

ASpeed SuperIO Port = 00h

------[ ACPI Temperatures & Fans ]------

_TZ_.THM0._TMP             :
_TZ_.THM1._TMP             :
_TZ_.THR0._TMP             :
_TZ_.THR1._TMP             :
_TZ_.TZ00._TMP             :
_TZ_.TZ01._TMP             :
_TZ_.RTMP                  :
_TZ_.RFAN                  :
_TZ_.RFAN(0)               :
_TZ_.RFAN(1)               :
_SB_.ATKD._HID             :
_SB_.ATKD.TMPR             :
_SB_.PCI0.LPC0.EC0_.CCTV   :
_SB_.PCI0.LPC0.EC0_.LRPM   :
_SB_.PCI0.LPC0.EC0_.HRPM   :
_SB_.PCI0.SBRG.EC0_.ECPU   :
_SB_.PCI0.SBRG.EC0_.TACH(0):
_SB_.PCI0.SBRG.EC0_.TACH(1):
_SB_.PCI0.SBRG.EC0_.TAH0   :
_SB_.PCI0.SBRG.EC0_.TAH1   :
_SB_.PCI0.SBRG.EC0_.ST00   :
_SB_.PCI0.SBRG.EC0_.SC01   :
_SB_.PCI0.SBRG.EC0_.SC02   :
_SB_.PCI0.SBRG.EC0_.SC03   :
_SB_.PCI0.SBRG.EC0_.SC04   :
_SB_.PCI0.SBRG.EC0_.SC05   :
_SB_.PCI0.SBRG.EC0_.SC06   :
_SB_.PCI0.SBRG.EC0_.TH0R   :
_SB_.PCI0.SBRG.EC0_.TH1R   :
_SB_.PCI0.SBRG.EC0_.F0TS   :
_SB_.PCI0.SBRG.EC0_.F1TS   :
_SB_.PCI0.PIB_.EC0_.TCRT   :
_SB_.PCI0.SBRG.EC0_.CTPM   :
_SB_.PCI0.SBRG.EC__.CPUT   :
_SB_.PCI0.SBRG.EC__.SYST   :
_SB_.PCI0.LPC_.EC0_.CTMP   :
_SB_.PCI0.LPCB.EC0_.CTMP   :
_SB_.PCI0.LPC_.EC0_.TMP1   :
_SB_.PCI0.LPC_.EC0_.TMP2   :
_SB_.PCI0.LPC_.EC0_.TMPI   :
_SB_.PCI0.LPC_.EC0_.TMPV   :
_SB_.PCI0.LPCB.EC0_.A1TP   :
_SB_.PCI0.LPCB.EC0_.A2TP   :
_SB_.PCI0.LPCB.EC0_.FAN0   :
_SB_.PCI0.LPCB.EC__.TS1R   :
_SB_.PCI0.LPCB.EC__.TS2R   :
_SB_.PCI0.LPCB.EC__.TS3R   :
_SB_.PCI0.LPCB.EC__.F1FL   :
_SB_.PCI0.LPCB.EC__.F1FH   :
_SB_.PCI0.LPCB.EC__.F2FL   :
_SB_.PCI0.LPCB.EC__.F2FH   :
_SB_.PCI0.LPC_.H8EC.RTMP   :
_SB_.PCI0.LPC_.H8EC.LTMP   :
_SB_.PCI0.LPC_.H8EC.MTMP   :
_SB_.PCI0.LPC_.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.CTMP   :
_SB_.PCI0.LPCB.H8EC.DTMP   :
_SB_.PCI0.LPCB.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.ITMP   :
_SB_.PCI0.LPCB.H8EC.MTMP   :
_SB_.PCI0.LPCB.H8EC.STMP   :
_SB_.PCI0.LPCB.H8EC.PFAN   :
_SB_.PCI0.LPCB.EC0_.OTPC   :
_SB_.PCI0.LPCB.EC0_.VGAT   :
_SB_.PCI0.LPCB.EC0_.CHPT   :
_SB_.PCI0.LPCB.EC0_.CPUT   :
_SB_.PCI0.LPCB.EC0_.SYST   :
_SB_.PCI0.LPCB.EC0_.DTS1   :
_SB_.PCI0.LPCB.EC0_.DTS2   :
_SB_.PCI0.LPCB.EC0_.DIMM   :
_SB_.PCI0.LPCB.EC0_.FANH   :
_SB_.PCI0.LPCB.EC0_.FANL   :
_SB_.PCI0.LPCB.EC0_.CUTP   :
_SB_.PCI0.LPCB.EC0_.PHTP   :
_SB_.PCI0.LPCB.EC0_.DIMT   :
_SB_.PCI0.LPCB.EC0_.INLE   :
_SB_.PCI0.LPCB.EC0_.PANT   :
_SB_.PCI0.LPCB.EC0_.F0RM   :
_SB_.PCI0.LPCB.EC0_.F0DT   :
_SB_.PCI0.LPCB.EC0_.F1RM   :
_SB_.PCI0.LPCB.EC0_.F1DT   :
_SB_.PCI0.SBRG.EC0_.CUTP   :
_SB_.PCI0.SBRG.EC0_.PHTP   :
_SB_.PCI0.SBRG.EC0_.DIMT   :
_SB_.PCI0.SBRG.EC0_.INLE   :
_SB_.PCI0.SBRG.EC0_.PANT   :
_SB_.PCI0.SBRG.EC0_.F0RM   :
_SB_.PCI0.SBRG.EC0_.F0DT   :
_SB_.PCI0.SBRG.EC0_.F1RM   :
_SB_.PCI0.SBRG.EC0_.F1DT   :
_SB_.SAMB.TMPC             :
_SB_.SAMB.TMPH             :
_SB_.STR0._TMP             :
_SB_.STR1._TMP             :
_SB_.STR2._TMP             :
_SB_.STR3._TMP             :
_SB_.STR4._TMP             :
_SB_.STR5._TMP             :
_SB_.STR6._TMP             :
_SB_.STR7._TMP             :
CPUT                       :
GPUT                       :
SYST                       :
FANT                       :
BATT                       :


Thank you.

Thank you.  I'm afraid the AIDA64 kernel driver is still not working on your system.  We've done several test runs, and the updated kernel driver in the latest AIDA64 beta build of 4944 works fine.  So the issue must be that either the old kernel driver got stuck on your system, and the new beta fails to load it for some reason.  Other than reinstalling AIDA64 and restarting Windows, I'm not sure what else can be done :( In other cases that procedure fixes similar issues all the time.

Share this post


Link to post
Share on other sites
8 minutes ago, Fiery said:

Thank you.  I'm afraid the AIDA64 kernel driver is still not working on your system.  We've done several test runs, and the updated kernel driver in the latest AIDA64 beta build of 4944 works fine.  So the issue must be that either the old kernel driver got stuck on your system, and the new beta fails to load it for some reason.  Other than reinstalling AIDA64 and restarting Windows, I'm not sure what else can be done :( In other cases that procedure fixes similar issues all the time.

Well, thank you for your help anyhow.

I will stick on previous beta for now and test with the next one :)

Share this post


Link to post
Share on other sites
5 hours ago, martellomartello1 said:

Hi everyone, I confirm that after the beta update v5.99.4944 Beta, the Nuvoton NCT6791D sensor he stops being read by AIDA64. The last working build 4936. No options or settings I tried to change had a solution.

We've done further test runs, but it still works properly for us.  The issue is still due to the kernel driver mixup: try to backup your settings (AIDA64.INI file in AIDA64 installation folder), remove AIDA64 from your system, restart Windows, download the latest AIDA64 beta build, and check it again.

Share this post


Link to post
Share on other sites

I also tried to delete the .ini file, but the problem persists. I tried, for scruple, a partition with windows just installed, but there is the same problem. If it can help, the motherboard is an ASUS RAMPAGE V EXTREME.

Share this post


Link to post
Share on other sites
1 hour ago, martellomartello1 said:

I also tried to delete the .ini file, but the problem persists. I tried, for scruple, a partition with windows just installed, but there is the same problem. If it can help, the motherboard is an ASUS RAMPAGE V EXTREME.

Please right-click on the bottom status bar of AIDA64 main window --> Sensor Debug --> ISA Sensor Dump. Copy-paste the full results into this topic, or attach the results as a TXT file to your post. You may need to enable status bar in AIDA64 / main menu / View first.


Thanks,
Fiery

Share this post


Link to post
Share on other sites

ISA SENSOR DUMP Build 4960 NOT WORKING:



------[ Versions ]------

Program Version : AIDA64 Extreme v5.99.4960 Beta
BenchDLL Version: 4.3.793-x64
Windows Version : Microsoft Windows 10 Home 10.0.17763.316 (64-bit)

------[ Motherboard Info ]------

Motherboard ID      : <DMI>
Motherboard Model   : Asus Rampage V Extreme
Motherboard Chipset : Intel Wellsburg X99, Intel Broadwell-E

DMI MB Manufacturer : ASUSTeK COMPUTER INC.
DMI MB Product      : RAMPAGE V EXTREME
DMI MB Version      : Rev 1.xx
DMI MB Serial       : 150852435300310
DMI SYS Manufacturer: ASUS
DMI SYS Product     : All Series
DMI SYS Version     : System Version
DMI SYS Serial      : System Serial Number
DMI BIOS Version    : 3902

ITE SuperIO Port           = 00h
ITE SuperIO HWMonitor Port = 0000h     (    0000h /     0000h)
ITE SuperIO HWMonitor MMIO = 00000000h (00000000h / 00000000h)
ITE SuperIO Device ID      = 0000h     (    0000h /     0000h)
ITE SuperIO Version        = 00h       (      00h /       00h)

Winbond SuperIO Port              = 00h
Winbond SuperIO HWMonitor Port/60 = 0000h (0000h / 0000h)
Winbond SuperIO HWMonitor Port/64 = 0000h (0000h / 0000h)
Winbond SuperIO Device ID         = 0000h (0000h / 0000h)

Fintek SuperIO Port           = 00h
Fintek SuperIO HWMonitor Port = 0000h (0000h / 0000h)
Fintek SuperIO Device ID      = 0000h (0000h / 0000h)

SMSC SuperIO Port           = 00h
SMSC SuperIO HWMonitor Port = 0000h (0000h / 0000h)
SMSC SuperIO Device ID      = 0000h (0000h / 0000h)

ASpeed SuperIO Port = 00h

------[ ACPI Temperatures & Fans ]------

_TZ_.THM0._TMP             :
_TZ_.THM1._TMP             :
_TZ_.THR0._TMP             :
_TZ_.THR1._TMP             :
_TZ_.TZ00._TMP             :
_TZ_.TZ01._TMP             :
_TZ_.RTMP                  :
_TZ_.RFAN                  :
_TZ_.RFAN(0)               :
_TZ_.RFAN(1)               :
_SB_.ATKD._HID             :
_SB_.ATKD.TMPR             :
_SB_.PCI0.LPC0.EC0_.CCTV   :
_SB_.PCI0.LPC0.EC0_.LRPM   :
_SB_.PCI0.LPC0.EC0_.HRPM   :
_SB_.PCI0.SBRG.EC0_.ECPU   :
_SB_.PCI0.SBRG.EC0_.TACH(0):
_SB_.PCI0.SBRG.EC0_.TACH(1):
_SB_.PCI0.SBRG.EC0_.TAH0   :
_SB_.PCI0.SBRG.EC0_.TAH1   :
_SB_.PCI0.SBRG.EC0_.ST00   :
_SB_.PCI0.SBRG.EC0_.SC01   :
_SB_.PCI0.SBRG.EC0_.SC02   :
_SB_.PCI0.SBRG.EC0_.SC03   :
_SB_.PCI0.SBRG.EC0_.SC04   :
_SB_.PCI0.SBRG.EC0_.SC05   :
_SB_.PCI0.SBRG.EC0_.SC06   :
_SB_.PCI0.SBRG.EC0_.TH0R   :
_SB_.PCI0.SBRG.EC0_.TH1R   :
_SB_.PCI0.SBRG.EC0_.F0TS   :
_SB_.PCI0.SBRG.EC0_.F1TS   :
_SB_.PCI0.PIB_.EC0_.TCRT   :
_SB_.PCI0.SBRG.EC0_.CTPM   :
_SB_.PCI0.SBRG.EC__.CPUT   :
_SB_.PCI0.SBRG.EC__.SYST   :
_SB_.PCI0.LPC_.EC0_.CTMP   :
_SB_.PCI0.LPCB.EC0_.CTMP   :
_SB_.PCI0.LPC_.EC0_.TMP1   :
_SB_.PCI0.LPC_.EC0_.TMP2   :
_SB_.PCI0.LPC_.EC0_.TMPI   :
_SB_.PCI0.LPC_.EC0_.TMPV   :
_SB_.PCI0.LPCB.EC0_.A1TP   :
_SB_.PCI0.LPCB.EC0_.A2TP   :
_SB_.PCI0.LPCB.EC0_.FAN0   :
_SB_.PCI0.LPCB.EC__.TS1R   :
_SB_.PCI0.LPCB.EC__.TS2R   :
_SB_.PCI0.LPCB.EC__.TS3R   :
_SB_.PCI0.LPCB.EC__.F1FL   :
_SB_.PCI0.LPCB.EC__.F1FH   :
_SB_.PCI0.LPCB.EC__.F2FL   :
_SB_.PCI0.LPCB.EC__.F2FH   :
_SB_.PCI0.LPC_.H8EC.RTMP   :
_SB_.PCI0.LPC_.H8EC.LTMP   :
_SB_.PCI0.LPC_.H8EC.MTMP   :
_SB_.PCI0.LPC_.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.CTMP   :
_SB_.PCI0.LPCB.H8EC.DTMP   :
_SB_.PCI0.LPCB.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.ITMP   :
_SB_.PCI0.LPCB.H8EC.MTMP   :
_SB_.PCI0.LPCB.H8EC.STMP   :
_SB_.PCI0.LPCB.H8EC.PFAN   :
_SB_.PCI0.LPCB.EC0_.OTPC   :
_SB_.PCI0.LPCB.EC0_.VGAT   :
_SB_.PCI0.LPCB.EC0_.CHPT   :
_SB_.PCI0.LPCB.EC0_.CPUT   :
_SB_.PCI0.LPCB.EC0_.SYST   :
_SB_.PCI0.LPCB.EC0_.DTS1   :
_SB_.PCI0.LPCB.EC0_.DTS2   :
_SB_.PCI0.LPCB.EC0_.DIMM   :
_SB_.PCI0.LPCB.EC0_.FANH   :
_SB_.PCI0.LPCB.EC0_.FANL   :
_SB_.PCI0.LPCB.EC0_.CUTP   :
_SB_.PCI0.LPCB.EC0_.PHTP   :
_SB_.PCI0.LPCB.EC0_.DIMT   :
_SB_.PCI0.LPCB.EC0_.INLE   :
_SB_.PCI0.LPCB.EC0_.PANT   :
_SB_.PCI0.LPCB.EC0_.F0RM   :
_SB_.PCI0.LPCB.EC0_.F0DT   :
_SB_.PCI0.LPCB.EC0_.F1RM   :
_SB_.PCI0.LPCB.EC0_.F1DT   :
_SB_.PCI0.SBRG.EC0_.CUTP   :
_SB_.PCI0.SBRG.EC0_.PHTP   :
_SB_.PCI0.SBRG.EC0_.DIMT   :
_SB_.PCI0.SBRG.EC0_.INLE   :
_SB_.PCI0.SBRG.EC0_.PANT   :
_SB_.PCI0.SBRG.EC0_.F0RM   :
_SB_.PCI0.SBRG.EC0_.F0DT   :
_SB_.PCI0.SBRG.EC0_.F1RM   :
_SB_.PCI0.SBRG.EC0_.F1DT   :
_SB_.SAMB.TMPC             :
_SB_.SAMB.TMPH             :
_SB_.STR0._TMP             :
_SB_.STR1._TMP             :
_SB_.STR2._TMP             :
_SB_.STR3._TMP             :
_SB_.STR4._TMP             :
_SB_.STR5._TMP             :
_SB_.STR6._TMP             :
_SB_.STR7._TMP             :
CPUT                       :
GPUT                       :
SYST                       :
FANT                       :
BATT                       :














ISA SENSOR DUMP Build 4936 WORKING:



------[ Versions ]------

Program Version : AIDA64 Extreme v5.99.4936 Beta
BenchDLL Version: 4.3.793-x64
Windows Version : Microsoft Windows 10 Home 10.0.17763.316 (64-bit)

------[ Motherboard Info ]------

Motherboard ID      : <DMI>
Motherboard Model   : Asus Rampage V Extreme
Motherboard Chipset : Intel Wellsburg X99, Intel Broadwell-E

DMI MB Manufacturer : ASUSTeK COMPUTER INC.
DMI MB Product      : RAMPAGE V EXTREME
DMI MB Version      : Rev 1.xx
DMI MB Serial       : 150852435300310
DMI SYS Manufacturer: ASUS
DMI SYS Product     : All Series
DMI SYS Version     : System Version
DMI SYS Serial      : System Serial Number
DMI BIOS Version    : 3902

ITE SuperIO Port           = 00h
ITE SuperIO HWMonitor Port = 0000h     (    0000h /     0000h)
ITE SuperIO HWMonitor MMIO = 00000000h (00000000h / 00000000h)
ITE SuperIO Device ID      = 0000h     (    0000h /     0000h)
ITE SuperIO Version        = 00h       (      00h /       00h)

Winbond SuperIO Port              = 2Eh
Winbond SuperIO HWMonitor Port/60 = 0290h (0290h / 0000h)
Winbond SuperIO HWMonitor Port/64 = 0A00h (0A00h / 0000h)
Winbond SuperIO Device ID         = C803h (C803h / 0000h)
Winbond Sensor ID A3/5C/reg$58    = A3 / 5C / C1

Fintek SuperIO Port           = 00h
Fintek SuperIO HWMonitor Port = 0000h (0000h / 0000h)
Fintek SuperIO Device ID      = 0000h (0000h / 0000h)

SMSC SuperIO Port           = 00h
SMSC SuperIO HWMonitor Port = 0000h (0000h / 0000h)
SMSC SuperIO Device ID      = 0000h (0000h / 0000h)

ASpeed SuperIO Port = 00h

------[ Nuvoton ISA Sensor Device at 0290 / Bank #0 ]------

0000  04 66 04 7F  00 FF FF FF  FF FF FF FF  FF FF FF FF
0010  04 00 04 66  04 FF 03 FF  40 7F 28 70  08 06 06 00
0020  71 7E D0 D0  7E F4 09 24  FF FF FF DA  00 00 00 00
0030  00 00 00 00  00 00 00 00  00 00 00 FF  FF FF FF FF
0040  03 00 00 FF  DF 00 1E FF  2D FF FF 10  00 55 02 A3
0050  05 FF FF FF  FF FF FF FF  C1 FF FF FF  FF 01 00 FF
0060  AA 0C FF FF  FF 01 00 FF  FF FF FF FF  FF FF FF FF
0070  00 0A 00 2A  00 2A 00 2A  00 2A 00 7F  80 FF FF FF
0080  FF 7F 3F BF  FF 05 05 05  00 00 00 00  00 00 00 00
0090  0A 00 00 00  00 FD FD FD  0A 95 EF 80  FF 40 46 C4
00A0  0E FF 00 00  FF 00 00 FF  00 00 80 66  06 06 01 00
00B0  00 00 00 00  00 00 34 00  04 00 00 34  28 00 04 00
00C0  FF FF FF FF  FF FF FF FF  FF 0E 04 05  FF FF FF FF
00D0  05 05 05 05  00 00 00 00  00 00 00 00  FD FD FD FD
00E0  55 80 00 00  00 FF FF FF  FF FF 00 00  00 00 00 00
00F0  00 00 00 00  00 00 00 00  00 00 00 0F  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #1 ]------

0000  10 00 40 01  01 01 01 3C  00 66 FF 66  00 FF FF FF
0010  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0020  FF 37 37 41  4B FF FF 66  66 B2 FF FF  FF FF FF FF
0030  FF 00 FF FF  00 4B 00 CC  02 FF FF FF  FF FF FF 00
0040  FF FF FF FF  FF 00 00 FF  FF FF FF FF  FF FF 02 FF
0050  2A 00 00 4B  00 50 00 FF  FF FF FF FF  FF FF FF FF
0060  FF FF FF FF  FF FF 11 00  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #2 ]------

0000  10 32 40 01  01 01 01 3C  00 7F 00 7F  00 FF FF FF
0010  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0020  FF 37 37 41  4B FF FF 7F  7F BF FF FF  FF FF FF FF
0030  FF 00 FF FF  00 4B 00 CC  02 01 00 00  00 00 00 00
0040  FF FF FF FF  FF 00 00 FF  FF FF FF FF  FF FF 02 FF
0050  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0060  FF FF FF FF  FF FF 11 00  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #3 ]------

0000  10 00 40 01  01 01 01 3C  00 00 FF 72  00 FF FF FF
0010  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0020  FF 3C 3C 41  46 FF FF 72  72 B2 FF FF  FF FF FF FF
0030  FF 00 FF FF  00 4B 00 CC  02 FF FF FF  FF FF FF 00
0040  FF FF FF FF  FF 00 00 FF  FF FF FF FF  FF FF 02 FF
0050  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0060  FF FF FF FF  FF FF 11 0A  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #4 ]------

0000  00 00 00 00  00 00 00 00  00 00 00 00  00 00 00 00
0010  00 00 00 00  00 00 00 00  00 00 00 FF  FF FF FF FF
0020  FF FF FF 96  64 96 64 E1  96 00 FF FF  FF FF FF FF
0030  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0040  FF FF 00 00  FF FF FF FF  FF FF 00 00  00 00 02 FF
0050  00 73 FF FF  00 00 00 FF  FF 1E 13 33  09 00 FF FF
0060  FF 01 00 00  00 00 00 00  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  71 7E D0 D0  7E F4 09 D7  D0 7F 27 70  10 17 06 00
0090  24 2A 7F 64  1F 7F 00 34  00 2A 2A 2A  2A 7F 30 7F
00A0  FF 24 FF FF  FF FF 66 7F  72 66 00 00  00 00 00 00
00B0  2E 08 0E 0A  FF 1F 4B 08  FF 1F FF 1F  00 00 FF FF
00C0  03 90 0B 83  00 00 02 30  00 00 00 00  FF FF FF FF
00D0  00 00 00 00  00 00 FF FF  FF FF FF FF  FF FF FF FF
00E0  66 7F 00 66  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  26 40 00 00  2A 00 04 00  50 00 51 00  00 00 00 FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #5 ]------

0000  FF FF 00 00  00 06 00 FF  0F FF FF FF  FF 00 00 FF
0010  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0020  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0030  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0040  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF 02 FF
0050  D7 D0 00 FF  00 00 00 00  00 00 00 00  00 00 00 00
0060  00 00 00 00  00 00 7F 00  3F FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #6 ]------

0000  00 00 00 00  00 00 00 FF  FF FF FF FF  FF FF FF FF
0010  00 04 00 04  04 04 FF FF  FF FF FF FF  FF FF FF FF
0020  FF 01 02 00  FF FF FF FF  FF FF FF FF  FF FF FF 1F
0030  2E 08 0E 0A  FF 1F 4B 08  FF 1F FF 1F  FF 1F FF 1F
0040  FF 1F FF 1F  02 02 02 02  02 02 FF FF  FF FF 02 FF
0050  7F 7F 7F 7F  00 00 03 90  0B 83 00 00  02 30 00 00
0060  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

------[ Nuvoton ISA Sensor Device at 0290 / Bank #7 ]------

0000  FF 95 02 10  00 00 00 00  00 64 00 00  00 00 00 00
0010  00 00 00 00  00 00 00 F0  AB F8 80 F8  80 F8 80 01
0020  26 02 07 00  00 00 EF 51  00 EF 00 00  00 00 00 00
0030  00 00 00 FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0040  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF 02 FF
0050  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0060  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0070  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

   0027 0150 0250 007D 007E 0490 0491 0492 0493 0494 0495 062B 062C 062D 071C 0720
T:   36   42  255  255  255   36   42  127  102   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  102   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  100   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  102   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  100   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  101   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  101   32  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  101   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  100   31  127  255  255  255  128   38
T:   36   42  255  255  255   36   42  127  100   31  127  255  255  255  128   38

   0020 0021 0022 0023 0024 0025 0026 0480 0481 0482 0483 0484 0485 0486 0487 0488 0489 048A 048B 048C 048D 048E 048F
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   0F   06   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   0F   06   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   0F   06   06   00   [ VID = 1.14929 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   0F   06   06   00   [ VID = 0.75317 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   0F   06   06   00   [ VID = 0.75317 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   08   06   06   00   [ VID = 0.75317 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   08   06   06   00   [ VID = 1.20740 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   08   06   06   00   [ VID = 1.17236 V ]
V:  71   7E   D0   D0   7E   F4   08   71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   10   0F   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   09   71   7E   D0   D0   7E   F4   09   D7   D0   7F   27   70   10   0F   06   00   [ VID = 1.20740 V ]

------[ NCT6791 ISA Sensor Device at 0A00 ]------

0000  71 7E D0 D0  7E F4 09 D7  D0 7F 28 70  10 06 06 00
0010  24 2A 7F 64  1F 7F 00 33  80 2A 2C 2A  2A 7F 7F 30
0020  24 02 66 7F  72 66 00 00  00 00 00 00  00 00 2D 12
0030  0E 12 FF 12  4C 12 FF 12  FF 12 03 9D  0B B1 00 00
0040  02 27 00 00  00 00 00 00  00 00 00 00  66 7F 00 66
0050  FF FF 26 40  00 00 00 00  00 00 00 00  00 00 00 00
0060  00 00 00 00  00 00 00 00  00 00 00 00  00 00 00 00
0070  00 2C 00 04  00 FF FF FF  FF FF FF FF  FF FF FF FF
0080  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
0090  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00A0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00B0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00C0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00D0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00E0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF
00F0  FF FF FF FF  FF FF FF FF  FF FF FF FF  FF FF FF FF

     10    11    12    13    1B    20    52    71    73    75
T:   36    42   127   100    42    36    38    44     4   255
T:   36    42   127   100    42    36    38    44     4   255
T:   36    42   127   101    41    36    38    41     3   255
T:   36    42   127   101    41    36    38    41     3   255
T:   36    42   127   101    41    36    38    41     3   255
T:   36    42   127   101    41    36    38    42     4   255
T:   36    42   127   102    41    36    38    42     4   255
T:   36    42   127   102    42    36    38    42     4   255
T:   36    42   127   102    42    36    38    42     4   255
T:   36    42   127   102    42    36    38    42     4   255

   0000 0001 0002 0003 0004 0005 0006 0007 0008 0009 000A 000B 000C 000D 000E 000F
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   71   08   0F   07   00   [ VID = 1.16187 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   32   0F   07   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   32   06   06   00   [ VID = 1.14929 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   32   06   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   32   06   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   32   06   06   00   [ VID = 0.75317 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   08   06   06   00   [ VID = 0.75317 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   27   70   08   06   06   00   [ VID = 1.20740 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   08   06   06   00   [ VID = 1.16809 V ]
V:  71   7E   D0   D0   7E   F4   08   D7   D0   7F   28   70   08   06   06   00   [ VID = 1.16187 V ]

------[ ACPI Temperatures & Fans ]------

_TZ_.THM0._TMP             :
_TZ_.THM1._TMP             :
_TZ_.THR0._TMP             :
_TZ_.THR1._TMP             :
_TZ_.TZ00._TMP             :
_TZ_.TZ01._TMP             :
_TZ_.RTMP                  :
_TZ_.RFAN                  :
_TZ_.RFAN(0)               :
_TZ_.RFAN(1)               :
_SB_.ATKD._HID             :
_SB_.ATKD.TMPR             :
_SB_.PCI0.LPC0.EC0_.CCTV   :
_SB_.PCI0.LPC0.EC0_.LRPM   :
_SB_.PCI0.LPC0.EC0_.HRPM   :
_SB_.PCI0.SBRG.EC0_.ECPU   :
_SB_.PCI0.SBRG.EC0_.TACH(0):
_SB_.PCI0.SBRG.EC0_.TACH(1):
_SB_.PCI0.SBRG.EC0_.TAH0   :
_SB_.PCI0.SBRG.EC0_.TAH1   :
_SB_.PCI0.SBRG.EC0_.ST00   :
_SB_.PCI0.SBRG.EC0_.SC01   :
_SB_.PCI0.SBRG.EC0_.SC02   :
_SB_.PCI0.SBRG.EC0_.SC03   :
_SB_.PCI0.SBRG.EC0_.SC04   :
_SB_.PCI0.SBRG.EC0_.SC05   :
_SB_.PCI0.SBRG.EC0_.SC06   :
_SB_.PCI0.SBRG.EC0_.TH0R   :
_SB_.PCI0.SBRG.EC0_.TH1R   :
_SB_.PCI0.SBRG.EC0_.F0TS   :
_SB_.PCI0.SBRG.EC0_.F1TS   :
_SB_.PCI0.PIB_.EC0_.TCRT   :
_SB_.PCI0.SBRG.EC0_.CTPM   :
_SB_.PCI0.SBRG.EC__.CPUT   :
_SB_.PCI0.SBRG.EC__.SYST   :
_SB_.PCI0.LPC_.EC0_.CTMP   :
_SB_.PCI0.LPCB.EC0_.CTMP   :
_SB_.PCI0.LPC_.EC0_.TMP1   :
_SB_.PCI0.LPC_.EC0_.TMP2   :
_SB_.PCI0.LPC_.EC0_.TMPI   :
_SB_.PCI0.LPC_.EC0_.TMPV   :
_SB_.PCI0.LPCB.EC0_.A1TP   :
_SB_.PCI0.LPCB.EC0_.A2TP   :
_SB_.PCI0.LPCB.EC0_.FAN0   :
_SB_.PCI0.LPCB.EC__.TS1R   :
_SB_.PCI0.LPCB.EC__.TS2R   :
_SB_.PCI0.LPCB.EC__.TS3R   :
_SB_.PCI0.LPCB.EC__.F1FL   :
_SB_.PCI0.LPCB.EC__.F1FH   :
_SB_.PCI0.LPCB.EC__.F2FL   :
_SB_.PCI0.LPCB.EC__.F2FH   :
_SB_.PCI0.LPC_.H8EC.RTMP   :
_SB_.PCI0.LPC_.H8EC.LTMP   :
_SB_.PCI0.LPC_.H8EC.MTMP   :
_SB_.PCI0.LPC_.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.CTMP   :
_SB_.PCI0.LPCB.H8EC.DTMP   :
_SB_.PCI0.LPCB.H8EC.GTMP   :
_SB_.PCI0.LPCB.H8EC.ITMP   :
_SB_.PCI0.LPCB.H8EC.MTMP   :
_SB_.PCI0.LPCB.H8EC.STMP   :
_SB_.PCI0.LPCB.H8EC.PFAN   :
_SB_.PCI0.LPCB.EC0_.OTPC   :
_SB_.PCI0.LPCB.EC0_.VGAT   :
_SB_.PCI0.LPCB.EC0_.CHPT   :
_SB_.PCI0.LPCB.EC0_.CPUT   :
_SB_.PCI0.LPCB.EC0_.SYST   :
_SB_.PCI0.LPCB.EC0_.DTS1   :
_SB_.PCI0.LPCB.EC0_.DTS2   :
_SB_.PCI0.LPCB.EC0_.DIMM   :
_SB_.PCI0.LPCB.EC0_.FANH   :
_SB_.PCI0.LPCB.EC0_.FANL   :
_SB_.PCI0.LPCB.EC0_.CUTP   :
_SB_.PCI0.LPCB.EC0_.PHTP   :
_SB_.PCI0.LPCB.EC0_.DIMT   :
_SB_.PCI0.LPCB.EC0_.INLE   :
_SB_.PCI0.LPCB.EC0_.PANT   :
_SB_.PCI0.LPCB.EC0_.F0RM   :
_SB_.PCI0.LPCB.EC0_.F0DT   :
_SB_.PCI0.LPCB.EC0_.F1RM   :
_SB_.PCI0.LPCB.EC0_.F1DT   :
_SB_.PCI0.SBRG.EC0_.CUTP   :
_SB_.PCI0.SBRG.EC0_.PHTP   :
_SB_.PCI0.SBRG.EC0_.DIMT   :
_SB_.PCI0.SBRG.EC0_.INLE   :
_SB_.PCI0.SBRG.EC0_.PANT   :
_SB_.PCI0.SBRG.EC0_.F0RM   :
_SB_.PCI0.SBRG.EC0_.F0DT   :
_SB_.PCI0.SBRG.EC0_.F1RM   :
_SB_.PCI0.SBRG.EC0_.F1DT   :
_SB_.SAMB.TMPC             :
_SB_.SAMB.TMPH             :
_SB_.STR0._TMP             :
_SB_.STR1._TMP             :
_SB_.STR2._TMP             :
_SB_.STR3._TMP             :
_SB_.STR4._TMP             :
_SB_.STR5._TMP             :
_SB_.STR6._TMP             :
_SB_.STR7._TMP             :
CPUT                       : <TYPE>0</TYPE><LEN>4</LEN><DATA>2</DATA>
GPUT                       :
SYST                       :
FANT                       :
BATT                       :



Share this post


Link to post
Share on other sites
On ‎2‎/‎28‎/‎2019 at 5:57 PM, martellomartello1 said:

I've also just noticed that there is so much information missing here with the version that has the problem.



The new kernel driver of AIDA64 v5.99.4960 Beta is not working on your system.  It's most likely because the old kernel driver got stuck in the driver cache of your Windows installation.  Try to remove all AIDA64 versions from your system, restart Windows and download + extract the latest AIDA64 beta build.

Share this post


Link to post
Share on other sites

Hi,

Just to let you know that none of the beta versions so far (up to 4966) has been able to read my sensors.

Removing Aida, restarting windows or modifying any settings does not seem to help.

How could I investigate further?

Regards,

PierrotIV

Share this post


Link to post
Share on other sites
17 hours ago, PierrotIV said:

Hi,

Just to let you know that none of the beta versions so far (up to 4966) has been able to read my sensors.

Removing Aida, restarting windows or modifying any settings does not seem to help.

How could I investigate further?

Regards,

PierrotIV

Can you please check the Event Logs?  Maybe it shows why your Windows installation fails (or refuses) to load the new AIDA64 kernel driver that was introduced in AIDA64 Beta Build 4944.

Share this post


Link to post
Share on other sites
On ‎3‎/‎14‎/‎2019 at 4:22 PM, PierrotIV said:

Hi,

Just to let you know that none of the beta versions so far (up to 4966) has been able to read my sensors.

Removing Aida, restarting windows or modifying any settings does not seem to help.

How could I investigate further?

Regards,

PierrotIV

We've fixed the issue in the latest AIDA64 beta build available at:

https://www.aida64.com/downloads/latesta64xebeta

Let me know how it works ;)

Share this post


Link to post
Share on other sites
7 hours ago, martellomartello1 said:

Yes!!



Yes!! It work!!!


....but, in my case I found two different temperatures of the same hardisk:


The old versions instead displayed only one.

Thank you for your feedback.  Yes, certain NVMe SSDs are capable of measuring 2 different temperatures.  The second temperature is most likely indicates the SSD controller's die temperature.

Share this post


Link to post
Share on other sites
On ‎4‎/‎2‎/‎2019 at 12:47 PM, PierrotIV said:

Hi,

It works with beta 4975.

Thx and regards,

PierrotIV

Thank you for your feedback ;)

Share this post


Link to post
Share on other sites

Create an account or sign in to comment

You need to be a member in order to leave a comment

Create an account

Sign up for a new account in our community. It's easy!

Register a new account

Sign in

Already have an account? Sign in here.

Sign In Now

  • Similar Content

    • By Deckard
      Hi,
      All of the system fans are no longer appearing in the sensor page Using AIDA64 extreme 5.99.4944 Beta
      RAD 1 header
      RAD 2 Header
      Chassis fan
      I cannot remember when it happend,  just noticed another post and I checked mine. same problem


    • By myarmor
      I was wondering why all the downloads are gone except the "try now" links?

      Beta, Downloads, and Downloads Archive is empty.
      I'm using FF 35.0.1.
    • By ded32
      Hello,
      I noticed that on Asus Rampage IV Extreme, AIDA64 sometimes outputs "Thread creation error: Insufficient memory for this operation" and after that readings of OPT1, OPT3, Case 2 and PCH fans become 0.0 RPM (I have OPT2, Case 1 and Case 2 fans unconnected so cannot say anything about them). CPU fan and CPU OPT fan readings are still OK.
      If I relaunch AIDA64 (File - Exit - Run again), readings become OK, and sometimes later the problem repeats.
      I have to confess that I have ASUS Suite II installed (because and only because AIDA64 missed OPTx temp support on Asus R4E!). After installation of AIDA64 Beta, I stopped running it, but process explorer shows its modules loaded and running (FanControlHelper.exe etc). So this may be result of interaction of AIDA64 and ASUS' DLLs (http://forums.aida64...ndpost__p__5532). It's not a problem for me, I plan to uninstall ASUS software. Just leaving it now only to help you in testing
      AIDA64 version: 2.50.2075 Beta.
      P.S. Fiery, thanks a lot for your great work - from another R4E user
      Never remove R4E support from AIDA64! BTW, you already have Option/Stability settings, you may add Asus Suite II compatibility there...
×
