Share your Sensorpanels

[Kouichi144]

いろいろ試してみましたが、GPUの温度などの設定が設定に表示されません。GPU RAMアイテムはありますか?



[JariKoi]

☹️

Sorry, this content is no longer available.

Remove by @JariKoi

[Kouichi144]

ありがとうございました。
これは修正されました。

[superfrog73]

So I've been fiddling with my panel, wasn't happy with the way I displayed individual core activity... thought it took away from the analog feel I was looking for.  So, looking for opinions of what I've got so far.

Took the cores and made a dedicated "LCD" and removed the clocks.  Made a sliding lighted indicator for CPU clocks, was trying to go for an analog but digital look from the '80s.  Need to now look what to do for the GPU to keep some assemblance of symmetry... any thoughts?  Maybe instead of GPU clock, FPS?

[pensioner600]

1920x 480. My first job. And the first message is here. I worked all night, but I haven’t done this before, this is the first time. It’s not finished yet, a lot still needs to be done, everything needs to be aligned and the background changed. You can also number the cores and threads

[ninjawhattt636]

Whats up everybody, This is my first post on this forum first sensor panel i pieced together iv got 10 hours in learning adia64 and the sensor panel its self. HUGE shoutout to whoever made this panel ! i love the layout and iv changed some things up from the original. Currently looking for a 5inch screen (current panel is 800x480) that supports adia64. iv added couple pics of my setup and Rog themed panel.



[Shephard]

19 minutes ago, ninjawhattt636 said:

Whats up everybody, This is my first post on this forum first sensor panel i pieced together iv got 10 hours in learning adia64 and the sensor panel its self. HUGE shoutout to whoever made this panel ! i love the layout and iv changed some things up from the original. Currently looking for a 5inch screen (current panel is 800x480) that supports adia64. iv added couple pics of my setup and Rog themed panel.

the cheapest option, in my opinion and what I use, is a display from Raspberry Pi, there are a lot of different options and sizes, the only thing you need to pay attention to is that the HDMI input must be present, such a display cost me 20 euros

[SanchoPancho]

for 3.5 inch (480x320)

[Vimyscout]

1920 x 480

Sensorpanel file is in WinRAR format.

Thanks for looking







HUD12.rar

[pensioner600]

Purple Planet 1920x480. Almost the finish. I did it for myself, I had to remember Photoshop. Use it whoever wants)) It’s bad that there are no CPU vddq and DRAM vdd/q voltage sensors; they are useful for memory overclocking.

Purple Planet.rar

[Shephard]

4 hours ago, pensioner600 said:

Purple Planet 1920x480. Almost the finish. I did it for myself, I had to remember Photoshop. Use it whoever wants)) It’s bad that there are no CPU vddq and DRAM vdd/q voltage sensors; they are useful for memory overclocking.

Purple Planet.rar 1.36 MB · 5 downloads

Question on an abstract topic, why do many people choose KF processors? I don’t think it’s because of the 20 dollar difference, and what’s most surprising is that it’s clear that in a cheap processor the built-in graphics doesn’t save the situation, but in a processor like the 13900K, is there really nowhere to fit a second video card?
For example, I stream to Twitch through a second card using the QSV codec, the ideal solution

[pensioner600]

2 hours ago, Shephard said:

Question on an abstract topic

In the batch from which I chose, the best ones for overclocking/undervolting were KF.  But this is rather an exception to the rule.  KF is a rejection based on the video core, but in my case it is better.

[Shephard]

2 hours ago, pensioner600 said:

In the batch from which I chose, the best ones for overclocking/undervolting were KF.  But this is rather an exception to the rule.  KF is a rejection based on the video core, but in my case it is better.

Just because of the 2% difference in overclocking, you have to give up an entire free video card..

[atxoxx]

Hi all, here is my first theme/setup
I share my setup here, inspired by some others here
Tried to put as much info as possible on my tiny screen
I'll improve with time !
For the background I don't know from where it comes (certainly this forum)

Theme is 1080*1920 (using my phone as monitor screen via Odospace LCD)
Some screen :

608562848_phonev110801920.oslcd

[E P]

On 11/16/2023 at 1:41 AM, Shephard said:



you want Aida64 to display brighter colors, I understand you, that is, that the color palette should have more saturated shades, if so, then I already wrote, you should wait a little and you will have the opportunity to use ready-made solutions..

I understand the limitation on what the transparent panels I have can display (i have significant back light and mostly white components to help).   I was just wondering if anyone had any expample screeenshots of what they may have used with a transparent panel.  Thanks.

[charles anderson]

On 3/31/2022 at 6:09 PM, carefree_dude said:

I gave up on the fan, i don't think it would look very good. Anyways I borrowed someone else's sensorpanel, and updated it to better fit my machine. Sadly having trouble finding original post to give credit. Surprisingly enough I had an almost identical setup to him so I didn't have to change much. anyways it is a 1024x600 panel. I wouldn't mind updating the RTX picture to match my card, as well as something different to put where "GPU Hotspot" is

rogsensorpanel.sensorpanel

Perfect

[JC_Nunes]

Hello, I'm not much of a talker here, but I decided to share my preset for the sensorpanel I'm using.

Principal PC - Resolution: 1920x480 (with FPS counter)

Secondary PC - Resolution: 1920x480 (without FPS counter)



Remembering that I am not the original owner of the preset, I just downloaded it here and made some changes!

Principal_PC.rar Secondary_PC.rar

[matsharp]

1032799985_rgbasus.sensorpanel

[OMiD1080p]

I recently finished my first sensor Panel for myself.

800x1280

[pensioner600]

When I click anywhere on the desktop, a bar appears on the second screen for a few seconds. Tried different settings. How to fix?

I found. In the taskbar settings, disable it.

Edited November 22, 2023 by pensioner600

[Psycho]

8 hours ago, pensioner600 said:

When I click anywhere on the desktop, a bar appears on the second screen for a few seconds. Tried different settings. How to fix?

I found. In the taskbar settings, disable it.

Windows Settings - Personalization -Taskbar - Taskbar behavior
Make the appropriate settings there

[caselcd1]

515



[antho]

On 10/15/2023 at 11:36 AM, notsobright said:



73502130_analogchernobyl.rar 3.83 MB · 82 downloads 1007677523_analogchernobyl.sensorpanel 4.03 MB · 85 downloads



[CoolBull]

Hey! everyone,

I'm thrilled to share my very first build with all of you! With the assistance of some fantastic online free templates and my own design touch, I proudly present to you my cool-looking first sensor display.

I've put a lot of effort into crafting this, and I'm excited to hear your thoughts and suggestions. Your feedback means a lot to me, and I'm open to any tips or ideas you may have to make it even better.

I hope you all like it as much as I enjoyed creating it! Cheers from  Australia.

[Nguyễn Minh Toàn]

anyone have gundam build?
